USW Lite 16 PoE

The Ubiquiti UniFi Switch Lite 16 PoE is a fully managed Layer 2 switch with sixteen Gigabit Ethernet ports for your RJ45 Ethernet devices. Eight ports also offer auto-sensing 802.3at PoE+ that provide up to a total of 45W PoE wattage for UniFi Access Points or other PoE devices. Below are its technical specifications:

Overview:

• Dimensions: 192 x 185 x 44 mm (7.6 x 7.3 x 1.7")
• Port Layout: (16) 1 GbE RJ45 ports
• Max. PoE Output: Up to PoE+
• Total PoE Availability: 45W
• Form Factor: Compact desktop, wall

Performance:

• Switching Capacity: 32 Gbps
• Total Non-Blocking Throughput: 16 Gbps
• Forwarding Rate: 24 Mpps
• Supported VLANs: 1000
• MAC Address Table Size: 8,000
• Packet Buffer Size: 0.5 MB
• Access Lists:
  • IPv4: 128
  • MAC: 128

Layer 2 Features:

• LACP Port Aggregation
• STP & RSTP
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
• IGMP Snooping
• 802.1X Control
• MAC-Based ACLs & Device Isolation
• DHCP Snooping & Guarding
• Egress Rate Limit
• Flow Control
• Storm Control
• Multicast & Broadcast Rate Limiting
• MAC Address Blocking
• IP-Based ACLs & Network Isolation
• MAC-Based Port Restriction
• Port Isolation
• Port Mirroring
• Jumbo Frames
• Loop Protection

Hardware:

• PoE Ports: 8 PoE+
• Max. PoE Wattage per Port by PSE: PoE+ 32W
• Max. Power Consumption:
  • 15W (Excluding PoE Output)
  • 60W (Including PoE Output)
• Power Method: Universal input, 100—240V AC, 50/60 Hz
• Power Supply: AC/DC internal, 60W
• Weight: 1.2 kg (2.6 lb)
• Enclosure Material: Polycarbonate
• Ambient Operating Temperature: -15 to 40°C (5 to 104°F)
• Ambient Operating Humidity: 10 to 90% noncondensing
• NDAA Compliant: Yes
• Certifications: CE, FCC, IC, Anatel

Software:

• Application Requirements: UniFi Network version 7.2.94 and later
