USW AGGREGATION

14.880,00 ден 17.558,40 ден with DDV one time, and
4.464,00 ден / year

An 8-port, Layer 2 switch made for 10G SFP+ connections.

The Ubiquiti UniFi USW-Aggregation is an 8-port, SFP+, layer 2 managed switch designed to provide high-bandwidth switch aggregation for your UniFi network. Link aggregation is also supported making the USW-Aggregation perfect for increasing capacity and availability on any UniFi network that deploys various interconnected topologies.

The Switch Aggregation (USW-Aggregation) is an 8-port, Layer 2 switch designed for 10G SFP+ connections. Below are its technical specifications:

Overview:

Dimensions: 442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7")
Port Layout:
- (8) 10G SFP+ ports (10G/1G)
Form Factor: Rack mount (1U)

Performance:

Switching Capacity: 160 Gbps
Total Non-Blocking Throughput: 80 Gbps
Forwarding Rate: 119 Mpps
Supported VLANs: 1,000
MAC Address Table Size: 16,000
Packet Buffer Size: 1.5 MB
Access Lists:
- IPv4: 128
- MAC: 128

Layer 2 Features:

LACP Port Aggregation
STP & RSTP
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection

Hardware:

Max. Power Consumption: 36W (Including SFP modules)
Power Method: Universal input, 100–240V AC, 50/60 Hz
Power Supply: Internal AC/DC, 36W
Ambient Operating Temperature: -5 to 40°C (23 to 104°F)
Ambient Operating Humidity: 10 to 90% noncondensing
Enclosure Material: SGCC steel
Weight:
- Without mounting brackets: 2.6 kg (5.8 lb)
- With mounting brackets: 2.7 kg (6 lb)
Certifications: CE, FCC, IC, Anatel
NDAA Compliant: Yes
