USW PRO Max 16

The Switch Pro Max 16 (USW-Pro-Max-16) is a 16-port, Layer 3 Etherlighting™ switch with 2.5 GbE support and versatile mounting options. Below are its technical specifications:

Overview:

• Dimensions: 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")
• Port Layout:
  • (12) 1 GbE RJ45 ports (1G/100M/10M)
  • (4) 2.5 GbE RJ45 ports (2.5G/1G/100M/10M)
  • (2) 10G SFP+ ports (10G/1G)
• Layer 3: Yes
• Form Factor: Rack mount (1U), desktop, wall
• Etherlighting™: Yes (ports illuminate to indicate port location, speed/link, and native VLAN/network)

Performance:

• Switching Capacity: 84 Gbps
• Total Non-Blocking Throughput: 42 Gbps
• Forwarding Rate: 62 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 16,000
• L3 Table Size:
  • ARP Entries: 6,000
  • IPv4 Routes: 512
• Packet Buffer Size: 1.5 MB
• Access Lists:
  • IPv4: 128
  • MAC: 128

Layer 3 Features:

• DHCP Server, DHCP Relay
• Inter-VLAN Routing
• Static Routing

Layer 2 Features:

• LACP, STP & RSTP, QoS (DSCP)
• Pro AV Profiles, IGMP Snooping
• Port Isolation, Mirroring, Jumbo Frames, and more

Hardware:

• Max. Power Consumption: 25W
• Power Method: AC/DC Adapter (included)
• Power Input Method: USB Type-C, 5V DC, 5A
• Enclosure Material: SGCC steel
• Ambient Operating Temperature: -5 to 40°C (23 to 104°F)
• Certifications: CE, FCC, IC, Anatel
• NDAA Compliant: Yes

Software:

• Application Requirements: UniFi Network version 8.1.127 and later

This switch is ideal for high-performance Layer 3 networking with advanced features and Etherlighting™ for streamlined cable management.
