USW 48 POE

32.860,00 ден 38.774,80 ден with DDV one time, and
9.858,00 ден / year

A 48-port, Layer 3 switch capable of high-power PoE++ output.

Tipovi	PoE , Standard

The Ubiquiti UniFi USW-48-POE is a configurable Gigabit Layer 2 switch with 48 Gigabit Ethernet ports including 32 auto-sensing 802.3at PoE+ ports, and 4 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-48-PoE features a 1.3" touch LCM to provide status.

The Switch 48 PoE (USW-48-POE) is a 48-port, Layer 2 PoE switch with a silent, fanless cooling system. Below are its technical specifications:

Overview:

Dimensions: 442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
Port Layout:
- 1 GbE RJ45: 48 ports (32 PoE+)
- 1G SFP: 4 ports
Max. PoE Output: Up to PoE+
Total PoE Availability: 195W
Form Factor: Rack mount (1U)

Performance:

Switching Capacity: 104 Gbps
Total Non-Blocking Throughput: 52 Gbps
Forwarding Rate: 77 Mpps
Supported VLANs: 1,000
MAC Address Table Size: 16,000
Packet Buffer Size: 1.5 MB

Layer 2 Features:

LACP Port Aggregation, STP & RSTP
Advanced IGMP Configuration, IGMP Snooping
802.1X Control, DHCP Snooping & Guarding
Port Isolation, Port Mirroring, Jumbo Frames
Voice VLAN, Loop Protection, and more

Hardware:

PoE Ports: 32 PoE+ ports
Max. PoE Wattage per Port:
- PoE: 15.4W
- PoE+: 32W
Max. Power Consumption:
- 45W (Excluding PoE Output)
- 240W (Including PoE Output)
Power Method: Universal input, 100–240V AC, 50/60 Hz
Power Supply: AC/DC, internal, 240W
Enclosure Material: SGCC steel
Ambient Operating Temperature: -5 to 40°C (23 to 104°F)
Ambient Operating Humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC, Anatel
NDAA Compliant: Yes
