UDB

5.580,00 ден 6.584,40 ден with DDV one time, and
1.674,00 ден / year

Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link.

UDB SUB

5 year warranty , remote support and management

1.674,00 ден 1.975,32 ден with DDV / year

The Ubiquiti UniFi UDB is a wireless PoE adapter designed to streamline network expansion and device connectivity. With its UniFi Wi-Fi Auto-Link technology, the UDB makes wireless bridging simple and intuitive, allowing users to quickly set up reliable, high-speed connections.

The UniFi Device Bridge (UDB) is a plug-and-play wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link. Below are its technical specifications:

Overview:

  • Dimensions: 130 x 55 x 34 mm (5.1 x 2.2 x 1.3")
  • WiFi Standard: WiFi 5
  • Spatial Streams: 2
  • Mounting Locations: Wall, table
  • Mounting: Wall (Included)
  • Power Method: 100–240V AC, 0.45A Max., 50/60 Hz

Performance:

  • MIMO:
    • 5 GHz: 2x2
  • Max. Data Rate:
    • 5 GHz: 866.7 Mbps (BW80)
  • Antenna Gain:
    • Internal: 5 dBi
    • External Omni: 4 dBi, 360° x 30°
  • Max. TX Power:
    • 5 GHz: 21 dBm
  • Supported Data Rates:
    • 802.11ac (WiFi 5): 6.5 Mbps to 866.7 Mbps
    • 802.11n: 6.5 Mbps to 300 Mbps
    • 802.11a: 6 to 54 Mbps
  • Wireless Security: WPA2 AES

Hardware:

  • Max. Power Consumption: 25W (AC input), 10W (Excluding PoE output)
  • Supported Voltage Range: 100–240V AC
  • Networking Interface: (1) GbE RJ45 port
  • Antennas:
    • (1) Internal antenna
    • (1) RP-SMA connector for external omni-antenna
  • Management: WiFi
  • Channel Bandwidth: 20/40/80 MHz
  • Weight: 200 g (7.1 oz)
  • Enclosure Material: Polycarbonate
  • Button: (1) Factory-reset
  • LEDs:
    • System: (4) Blue: signal, (1) White/blue: indicator
  • NDAA Compliant: Yes
  • Certifications: CE, FCC, IC
  • Operating Frequency:
    • US/CA: 5150 - 5850 MHz
    • Worldwide: 5150 - 5875 MHz
  • Ambient Operating Temperature: -10 to 40°C (14 to 104°F)
  • Ambient Operating Humidity: 5 to 95% noncondensing

This device is ideal for bridging UniFi Protect PoE cameras, Talk phones, and various IoT devices via an Ethernet connection.

Installation Guide

Datasheet

CE Doc
